Model NumberE502-KGNN-S00
ColorBlack
MaterialsExterior: Steel
Left Side Panel: Tempered Glass
Right Side Panel: Steel
Dimensions(L x W x H)Incl. Protrusions: 474 x 230 x 481mm
Excl. Protrusions: 435 x 230 x 465 mm
Volume (Liters Incl. Protrusions): 49.73 L
Motherboard SupportITX / Micro ATX / ATX (Supporting Back-connector Motherboard) /
E-ATX (*up to 12"x10.9"/ 30.5cmx27.7cm motherboards,
may impact cable management)
Expansion Slots7
Drive Bays5.25“ ODD: N/A 3.5” HDD: 2
2.5” SSD: 2 (Max.6)
I/O PanelUSB Ports: USB 3.2 Gen 1 Type A x 1 / USB 3.2 Gen 1 Type C x 1
Audio In / Out: 1x 3.5mm Combo
Pre-installed Fan(s)Front: 120 mm x 3 ARGB
Fan SupportFront (Filtered): 140 mm x 3 / 120 mm x 3 Top (Filtered): 140 mm x 2 / 120 mm x 3
Rear: 120 mm x 1
Radiator SupportFront: 120 / 140 / 240 / 280 / 360 / 420 mm (Limit: 457*140*27 mm)
Top: 120 / 140 / 240 / 280 / 360 mm
Rear: 120mm
ClearancesCPU Cooler: 170 mm Power Supply: 170 / 210mm (w/o HDD Cage) Graphics Card: 360 / 410 mm (w/o front radiator)
Cable Routing(Behind MB Tray): 33 – 35 mm
Dust FiltersTop/Bottom/Front
Power Supply SupportATX
Warranty2 Years
