Supported CPUSocket 1150 / Intel Pentium / Celeron / i3 / i5 / i7
(4th & 5th Generation) Series Processors
ChipsetIntel H81 Chipset With 2 Years Brand Warranty
Memory supported2 x DDR3 DIMM memory slots,
Memory up to 16GB,
Supports DDR3 1066/1333/1600 MHz memory
BIOSAMI BIOS
I/O Interface1 x HDMI, 1 x VGA, 4 x USB2.0, 2 x USB3.0, 1 x Rj45, 1x 3-in-1 Audio Jacks
Onboard interface1 x 24 pin ATX Power Connector, 1 x 8 Pin ATX 12V Power Connector, 2 x USB 2.0 Header,
1 x Front Audio Connector, 1 x Front Panel Connector, 1 x Speaker Connector,
1 x 4 pin CPU fan connector, 1 x SYS Fan Connector, 2 x SATA 2.0 Ports, 2 x SATA3.0 Ports ,
1 x clear CMOS Connector., 1x M.2 Slot
Integrated SoundWith 5.1-Channel HD Audio
Integrated LANSupports RTL8106E 10/100 Mbps Ethernet LAN
Expansion Slot1 x PCI Express 2.0 x16 size slot
Form factorMicro-ATX
Country of OriginPeople’s Republic of China
Package contentsUser Manual
H81M2 Motherboard1 U
SATA Cable1 U
I/O Backplate1 U
Driver Disc1 U
User Manual1 U
